Unit cost
THB 418,452.00
/set
Wholesale discounts
Quantity
Discount
Price per unit
1+
0%
THB 418,452.00
Options
กรุณาเลือกประเภท กรุณาเลือกประเภท
Total Cost
THB 418,452.00
Amount
/set
1
Brand parts:
BYHX-A-KM512i-4H Board
Honsoft UltraPrint RIP software
Japanese PANASONIC 400W AC servo motor
Japanese NSK bearing
Germany IGUS drag train
Germany IGUS Power cable
Italy Megadyne belt 15MM
American Value Plastics tube connector
Taiwan Hiwin linear guide with two pcs mute slider
JYY DC ink Pump
JYY Solenoid Valve
Configuration:
Classic Printer body
High quality 200mm wide printing bed
Big Metal beam
Intelligent infrared heating system
LED lights at cleaning postion and printing bed
4 in 1 heating control system
Rear-Printing bed-front-Printhead heater
Positive pressure ink supply system
Separate ink purging system
Lift type carriage
Unique printhead protection stack
Multifunction Feeding system
Printing speed and Resolution:
8H-2pass-240㎡/h-480*360dpi
8H-3pass-160㎡/h-480*540dpi
8H-4pass-120㎡/h-480*720dpi
Package:
N.W=700KG
G.W=850KG
Package (Complete): 5.0*1.15*1.6=9.2CBM
Package (Separate): 4.57CBM
1) 4.71*0.75*1.11M
2) 1.05*0.91*0.68M
Details:
