ราคาต่อชิ้น
THB 1,533,777.00
/set
ส่วนลดขายส่ง
จำนวน
ส่วนลด
ราคาต่อหน่วย
1+
0%
THB 1,533,777.00
ค่าใช้จ่ายรวม
THB 1,533,777.00
จำนวน
/set
1
| Print Width | 600-1900mm |
| Printhead | Epson i3200 |
| Numbers Of Printheads | 16 Heads |
| Control System | Hoson |
| RIP Software | PF/EFI/RIP |
| Ink & Color Configuration | Pigment ink MYCK / MYCK+lc lm lk llk / MYCK+lc lm lk+R |
| Printing Efficiency | 4/6/8 pass 60-120m²/h |
| Ink Path Configuration | 8 Channel 5L ink tank (Negative Ink Supply) + Secondary ink bottle |
| Print Media | 17g~400g Paper roll media |
| Media Feeding Method | Pressure roller paper feeding |
| Media Winding & Unwinding Unit | 10000m unwind capacity |
| Main Mechanical Configuration | Cabinet-type structure + steel beam + dual THK20 guide rail + Linear Motor + Adjustable 3-roller press wheels |
| Printing Platform / Rear Arc Plate | Smooth surface suction platform heating / Rear arc electric heating |
| Carriage | Tool-free adjustment base plate + Anti-collision device |
| Capping Station Cleaning | Auto-clean (liftable capping station + integrated wiper blade) |
| Drying Unit | External auto-sensing drying unit (3 groups front-mounted) |
| Winding-Unwinding Control System | AC Servo Motor controlled by Inverter |
| Air Shaft | 3'' aluminum ribbed air shaft / 6'' adapter |
| Maximum Media Diameter | 700mm (Unwinding) |
| Machine Weight | 2000kg |
| Machine Dimensions | 4140mm*1550mm*1830mm |
| Packing Dimensions | 4200mm*1500mm*1950mm |
| Environmental Requirements | Temperature 25-28°C / Humidity 45%-70% |
| Power Supply Requirements | Single phase AC220V / 4500W / 50-60HZ |
| Air Supply Requirements | Dry compressed air 0.4-0.6Mpa |
