800mm/1200mm CO2 Laser Plotter Cutter Machine
120cm
ราคาต่อชิ้น
THB 150,572.00
/set
ส่วนลดขายส่ง
จำนวน
ส่วนลด
ราคาต่อหน่วย
1
0%
THB 150,572.00
ตัวเลือก
กรุณาเลือกประเภท กรุณาเลือกประเภท
ค่าใช้จ่ายรวม
THB 150,572.00
จำนวน
/set
1
800mm/1200mm CO2 Laser Plotter Cutter Machine
The PRO series is equipped with a carbon dioxide glass laser tube and ordinary stepper motors (the precision and speed can meet the needs of most customers). This can solve the problems such as high labor costs, expensive procurement prices, large floor space, the need for single-sheet cutting of materials, and the requirement of personnel on duty for material replacement when users use ordinary lettering machines, platform laser machines, and laser marking machines. The CCD model uses a high-precision camera to automatically identify the marking points, truly achieving automatic edge tracing. With a powerful software automatic scanning function, it can automatically generate cutting contours after importing pictures, saving the layout time.
The machine can perform semi-transparent and fully transparent cutting operations simultaneously, saving the time for manual waste removal and improving work efficiency. It is suitable for various high-elastic films in the garment printing industry, such as reflective films, PU films, TPU films, silicone films, flocking films, gold mesh films, laser films, etc., as well as leather, fabrics, kraft paper, and garment pattern making.
Specification:
| Model | 800PRO-CCD | 1200PRO-CCD |
| Features | Co2 laser+CCD | |
| Laser Power | 50W | 80W |
| Paper feed width | 980mm | 1390mm |
| Carving width | 800mm | 1200mm |
| Carving length | Infinite Length | |
| Engraving thickness | ≤1mm | |
| Paper feeding system | Segmented Knurled Aluminum Shaft/Integrated Steel Spike Shaft | |
| Paper pressing device | Double spring adjustable pressure bar set | |
| Drive method | Stepper motor | |
| Carving speed | 10-800mm/s | |
| Laser current | 0-30mA | |
| Working voltage | 220V±10% 50/60Hz | |
| Machine Power | 400-450W | |
| Interface Types | USB port,、USB drive,、WIFI | |
| Output Software | AutoLaser、CorelDRAW、signmaster、CAD、AI | |
| Working Environment | Temperature Range: +1°C to +35°C (±1°C tolerance) Humidity Range: 10% to 50% RH (Non-condensing) |
|
