800mm 45W RFT Laser Plotter Cutter Machine
Precio unitario
THB 148.848,00
/unidad
Descuentos por volumen
Cantidad
Descuento
Precio por unidad
1
0%
THB 148.848,00
Costo total
THB 148.848,00
Cantidad
/unidad
1
800mm 45W RFT Laser Plotter Cutter Machine
the FRT series is equipped with a metal radio frequency laser tube and servo motors (which can provide a more refined cutting effect and higher cutting speed to meet the needs of high-end customers).This can solve the problems such as high labor costs, expensive procurement prices, large floor space, the need for single-sheet cutting of materials, and the requirement of personnel on duty for material replacement when users use ordinary lettering machines, platform laser machines, and laser marking machines. The CCD model uses a high-precision camera to automatically identify the marking points, truly achieving automatic edge tracing. With a powerful software automatic scanning function, it can automatically generate cutting contours after importing pictures, saving the layout time.
The machine can perform semi-transparent and fully transparent cutting operations simultaneously, saving the time for manual waste removal and improving work efficiency. It is suitable for various high-elastic films in the garment printing industry, such as reflective films, PU films, TPU films, silicone films, flocking films, gold mesh films, laser films, etc., as well as leather, fabrics, kraft paper, and garment pattern making.
Specification:
| Function | Laser cutting |
| CCD | Select Configuration |
| File format | PDF/SVG/AI/PLT/DXF/DST/DSB/BMP/JPG/PNG/GIF/ISO/CUT/DAT |
| Laser type | RF laser 45w |
| Laser power | 45W |
| Wavelength | 10.6nm |
| Maximum compatible size | 980mm |
| Maximum cutting fit size | 800mm |
| Cutting precision | 0.05 |
| Motor type | servo motor |
| Machine power | ≤1000W |
| Support langpage display Simnplified | Chinese/English/TraditionalChinese/Korean/Russian/Italian/Spanish/Portuguese/Vietnamese |
| Suitable cutting thickness | ≤2.2mm |
