QL-1325 6 Heads Router CNC
Precio unitario
THB 299.089,00
/unidad
Descuentos por volumen
Cantidad
Descuento
Precio por unidad
1
0%
THB 299.089,00
Costo total
THB 299.089,00
Cantidad
/unidad
1
Description:
1.6 Spindle Multi Head Cnc Machine
2.Time-saving woodworking CNC router
3.High-efficiency cnc router
4.Can work for cylinder materials and plate materials
Specifications:
| Machine type | QL-1325 | Optional configuration |
| Working stroke | 1300*2500*200 | Can be customized |
| The structure of the machine | Steel structure body, surface profile | Square table / adsorption bed structure |
| The size of the machine | 1950*3100*1650 | |
| Spindle power | 3KW water cooled spindle | The specified power / air / multi head |
| The maximum working speed | 15m/min | |
| Working voltage | AC380V, 50HZ | AC220V, 50HZ |
| Operating system | Weihong system | DSP handle or designated system |
| Working way | Stepper motor | Servo motor |
| Carving instruction | G code, HPGL, U00, MMG, PLT | |
| Transmission mode | XY axis gear rack, Z axis ball screw drive | |
| Available tool | φ3.175-φ12.7 |
Application:
